FK55series -FAN-AND-FILTER.pdf
Size:2024-03-13 16:42:40
Product Features
1. It is made of high-quality environmental Acrylonitrile butadiene styrene, which is safe, reliable, durable, and can be customized with flame retardant materials, conforming to UL94-V0
2. Front cover buckle installation for easy replacement of filter cotton
3. With indicator light for easy identification of whether the fan is in production or not
4. The IP protection level can reach IP54/IP55
5. The standard color is 7035, and other colors can be customized
FK5521 series fan-and-filter
| Picture | Brands | Rated Voltage | Rated Current | Overall Dimensions | Frequency | Protection Code | Qualification |
|---|---|---|---|---|---|---|---|
 |
LINKWELL |
220V/240V 110V/120V 24V |
0.07A/0.06A 0.14A/0.13A 0.18A |
109X109mm | 50/60Hz | IP54 | CE CCC |
FK5522 series fan-and-filter
| Picture | Brands | Rated Voltage | Rated Current | Overall Dimensions | Frequency | Protection Code | Qualification |
|---|---|---|---|---|---|---|---|
 |
LINKWELL |
220V/240V 110V/120V 24V |
0.12A/0.11A 0.24A/0.22A 0.35A |
150X150mm | 50/60Hz | IP54 | CE CCC |
FK5523 series fan-and-filter
| Picture | Brands | Rated Voltage | Rated Current | Overall Dimensions | Frequency | Protection Code | Qualification |
|---|---|---|---|---|---|---|---|
 |
LINKWELL |
220V/240V 110V/120V 24V |
0.12A/0.11A 0.24A/0.22A 0.35A |
204X204mm | 50/60Hz | IP54 | CE CCC |
FK5524 series fan-and-filter
| Picture | Brands | Rated Voltage | Rated Current | Overall Dimensions | Frequency | Protection Code | Qualification |
|---|---|---|---|---|---|---|---|
 |
LINKWELL |
220V/240V 110V/120V 24V |
0.12A/0.11A 0.24A/0.22A 0.35A |
254X254mm | 50/60Hz | IP54 | CE CCC |
FK5525 series fan-and-filter
| Picture | Brands | Rated Voltage | Rated Current | Overall Dimensions | Frequency | Protection Code | Qualification |
|---|---|---|---|---|---|---|---|
 |
LINKWELL |
220V/240V 110V/120V
|
0.30A/0.28A 0.52A/0.5A
|
250X250mm | 50/60Hz | IP54 | CE CCC |
FK5526 series fan-and-filter
| Picture | Brands | Rated Voltage | Rated Current | Overall Dimensions | Frequency | Protection Code | Qualification |
|---|---|---|---|---|---|---|---|
 |
LINKWELL |
220V/240V 110V/120V
|
0.29A/0.37A 0.52A/0.55A
|
325X325mm | 50/60Hz | IP54 | CE CCC |
FK5527 series fan-and-filter
| Picture | Brands | Rated Voltage | Rated Current | Overall Dimensions | Frequency | Protection Code | Qualification |
|---|---|---|---|---|---|---|---|
 |
LINKWELL |
220V/240V 110V/120V
|
0.52A/0.65A 0.9A/0.95A
|
325X325mm | 50/60Hz | IP54 |
CE CCC
|
FK5528 series fan-and-filter
| Picture | Brands | Rated Voltage | Rated Current | Overall Dimensions | Frequency | Protection Code | Qualification |
|---|---|---|---|---|---|---|---|
 |
LINKWELL |
220V/240V 110V/120V
|
0.52A/0.65A 0.9A/0.95A |
323X323mm | 50/60Hz | IP54 |
CE CCC
|
FK5529 series fan-and-filter
| Picture | Brands | Rated Voltage | Rated Current | Overall Dimensions | Frequency | Protection Code | Qualification |
|---|---|---|---|---|---|---|---|
 |
LINKWELL |
220V/240V 110V/120V
|
0.52A/0.65A 0.9A/0.95A |
323X323mm | 50/60Hz | IP54 |
CE CCC
|
